Ball valve
Cast steel floating ball valve
Product name: Split cast steel floating ball valve
DN: 1/2”(15)~ 8”(200)
CLASS(PN): 150LB(16)~600LB(100)
Available materials: cast iron, stainless steel SS304, SS316, SS316L, 904L, duplex stainless steel CD4MCu, 2205, 2507, Alloy 20, Hastelloy, Titanium, Monel, Nickel...
-
							Parameters
-
							Features
-
							Structure
-
							MOC
-
							Configuration
-
							Application
-
							Performance
None
						| Body structure: | Bolted body, cast steel |
| Valve seat: | Self-Relief / Double Piston Effect Seat / Upstream Self-Relief Valve Seat Downstream Double-Piston Effect Seat (Optional) |
| Ball: | Floating ball,solid |
| Flow pass: | Full bore / reduced diameter (optional) |
| Valve stem: | Anti-blowout, can be lengthened (optional) |
| Operation mode: | Manual / electric / pneumatic / pneumatic-hydraulic linkage / electro-hydraulic linkage / hydraulic (optional) |
| Seal: | Soft seal / metal seal / composite seal (primary metal seal + secondary soft seal) |
| Grease injection valve: | Not applicable |
| Vent valve: | Not applicable |
| Sewage valve: | Not applicable |
| Locking device: | Optional |
| Leak rating: | Soft seal: ISO 5208 Class A, metal seal: ISO 5208 Class C or higher, ANSI VI |
None
						| Material of main parts | |
| Valve body | Carbon steel / stainless steel / alloy steel forgings |
| Ball | Carbon steel / stainless steel / alloy steel forging nickel / chrome / spray welding hard alloy |
| Support ring | Carbon steel / stainless steel / alloy steel forging nickel / chrome / spray welding hard alloy |
| Valve seat | PTFE, RPTFE, VITON, NYLON, DEVLON, MOLON, PEEK/Seal face spray welding, tungsten carbide |
| Valve stem | Stainless steel / alloy steel / INCONEL, etc. |
| Packing | PTFE, graphite , etc. |
| Bolts and nuts | A193/A194, A320, etc. |
None
						| Pressure temperature class: | ASME B16.34 |
| Design: | BS 5351, API 608, ASME B16.34, API 6D, GB, GOST, DIN, BS |
| Test: | API 6D / API 598 / GB/T 13927 and other relevantNational standards. |
| Structure length: | API 6D, ANSI B16.10, GB 12221, GOST, DIN, BS/ manufacture standard / user requirements. |
| Connection end: | BW (ASME B16.25, ASME B31.8 / GB / T12224 and other national standards), RF (ASME B16.5, ASME B16.47, GB / JB / HG / GOST, DIN, etc.), RTJ (ASME B16. 5, ASME B16.47, GB / JB / HG / GOST, DIN, etc.), BW + PUP (the length of the transition tube is customized) |
| Fire protection requirements: | API 607/API 6FA/BS 6755 |
| Anti-static electricity: | API 608/BS 5351 |
| Valve anti-sulfur: | NACE MR. 0175 |
The valve body is made of castings, and non-destructive testing is used to prevent possible casting defects, and the construction cost is low.Split bolt connection for easy maintenance.
